68P80801E30-A 5/1/2002 4-15
Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
1-6 Channel GEN 4 or 900 MHz RFDS Site
Cables
Table 4-10 lists the required cables for a 1-6 channel GEN 4 or 900 MHz
RFDS site.
7-12 Channel GEN 4 or 900 MHz RFDS
Expansion Site Cables
Table 4-11 lists the required cables for a 7-12 channel GEN 4 or 900 MHz
RFDS expansion site.
Table 4-10 1-6 Channel 800 MHz GEN 4 / 900 MHz RFDS Site Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to Main RF Cabinet
0112004Z29 Ethernet 1 Main RF Cabinet to Expansion RF
Cabinet
0112004Z29 5 MHz/1 PPS 1
Site controller to Main RF Cabinet
3084225N42 Alarms 1
Site controller to Main RF Cabinet
Table 4-11 7-12 Channel 800 MHz GEN 4 / 900 MHz RFDS Expansion Site
Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to Main RF Cabinet
0112004Z29 Ethernet 1 Main RF Cabinet to Expansion RF
Cabinet
0112004Z29 5 MHz/1 PPS 1 Site controller to Main RF Cabinet
0112004Z29 5 MHz/1 PPS 1 Main RF Cabinet to Expansion RF
Cabinet
3084225N42 Alarms 1 EAS/EAS2 to Main RF Cabinet
3084225N42 Alarms 1 EAS/EAS2 to Expansion RF
Cabinet
