Gen 3 Site Controller System Manual Chapter 6 System Testing
Base Radio Registration
Base Radio Registration
Checking Base Radio connectivity
1. At the iSC> prompt, type: ping br
All Base Radios connected on the ethernet will be pinged.
Note: Quad BR must be switched to test mode, by performing diagnostic
reset (press reset button located on the BR front panel and follow on
screen instructions), in order to communicate with iSC. Refer to
System Testing section in Volume 1 (System Installation and
Testing) of EBTS manual for more information.
2. Verify the following messages on the service computer.
Cab/pos number and ethernet address will be displayed for BRs that
respond successfully:
The column Cab/Pos represents cabinet and position of the Base Radio. For
example, 13 is the Base Radio in cabinet 1 position 3.
Note: BR position 1 (BR1) represents the BR mounting position within the
cabinet which is closest to the floor. Position 5 represents the highest
from the floor.
iSC> ping br
Cab/Pos Ethernet Address Platform
---------- ---------------------- -------------
11 08:00:3e:c0:1c:10 Legacy BR
12 08:00:3e:c0:1c:11 Legacy BR
13 08:00:3e:c0:1c:12 Legacy BR
14 08:00:3e:c0:1c:13 Legacy BR
21 08:00:3e:c0:1c:14 Quad BR
22 08:00:3e:c0:1c:15 Quad BR
31 08:00:3e:c0:1c:16 Quad BR
32 08:00:3e:c0:1c:17 Quad BR
