Motorola iDEN Site Controller User Manual

68P80801E30-A 5/1/2002 3-33
Gen 3 Site Controller System Manual Chapter 3 Pre-Installation
Recommended Tools, Equipment, and Parts
Recommended Test Equipment
Table 3-9 lists the recommended test equipment for installation. These are
not included as part of the system shipment and must be procured locally.
All model numbers are Motorola part numbers, unless noted otherwise.
Table 3-9 Recommended test equipment for installation
Test Equipment Model/Type Supplier Purpose
communication
software
Procomm
Plus (or
equivalent)
DataStorm host
communication
digital multimeter
(only 1 required)
Fluke 77 Fluke DC measurements
R1037A Motorola DC measurements
R1073A Motorola DC measurements
file compression
software
PKUnzip PKWare compress/
decompress large
files
ground resistance
ohmmeter
AEMC 3700
clamp-on
ground tester
locally
procured
measure for
adequate ground
RF attenuators refer to the Parts and Suppliers
appendix
protection for
R2660 and used
with the
equipment for RF
attenuation
service computer refer to the Systems Testing
chapter
local service
terminal
communication cable
between PC service
computer and the
equipment
n/a n/a DB9 male / RS232
male used with
RS232 female /
DB9 male. Pinouts
from DB9 to DB9
must be straight
through
communication cable
between Macintosh
®
service computer and
the equipment
n/a n/a Din 8 male / DB9
male
service monitor R2660 w/
iDEN
Motorola station alignment
