Motorola iDEN Site Controller User Manual

68P80801E30-A 5/1/2002 4-13
Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
Sectored Site Cables
Table 4-7 lists the required cables for a three-sectored site.
800 MHz Duplex Hybrid Expansion RFDS intercabinet cabling
Intercabling between the Control Cabinet and the RF Cabinets for systems
equipped with Duplex Hybrid Expansion RF Distribution Systems is listed
below. Choose the appropriate table below, then refer to the appropriate
instructions for connecting the required intercabling.
5-8 Channel Duplex Hybrid Expansion Site
Cables
Table 4-8 lists the required cables for a 5-8 channel duplex hybrid expansion
site.
Table 4-7 Sectored Site Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to RF Cabinet #1
0112004Z29 Ethernet 1 RF Cabinet #1 to RF Cabinet #2
0112004Z29 Ethernet 1 RF Cabinet #2 to RF Cabinet #3
0112004Z29 5 MHz/1 PPS 1 Site controller to RF Cabinet #1
0112004Z29 5 MHz/1 PPS 1 RF Cabinet #1 to RF Cabinet #2
0112004Z29 5 MHz/1 PPS 1 RF Cabinet #2 to RF Cabinet #3
3084225N42 Alarms 1 EAS/EAS2 to RF Cabinet #1
3084225N42 Alarms 1 EAS/EAS2 to RF Cabinet #2
3084225N42 Alarms 1 EAS/EAS2 to RF Cabinet #3
Table 4-8 5-8 Channel Duplex Hybrid Expansion Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to Main RF Cabinet
0112004Z29 Ethernet 1 Main RF Cabinet to Expansion RF
Cabinet
0112004Z29 5 MHz/1 PPS 1 Site controller to Main RF Cabinet
0112004Z29 5 MHz/1 PPS 1 Main RF Cabinet to Expansion RF
Cabinet
3084225N42 Alarms 1 Site controller to Main RF Cabinet
3084225N42 Alarms 1 Site controller to Expansion RF
Cabinet
