Motorola iDEN Site Controller User Manual

Appendix B Parts & Suppliers Gen 3 Site Controller System Manual
B-12 68P80801E30-A 5/1/2002
GNB Technologies
829 Parkview Boulevard
Lombard, IL 60148
Phone: 708 629-5200
Phone: 800 872-0471
Fax: 708 629-2635
Refer to Table B-4 to determine the proper wire lug for the connection of
that wire to the Power Supply Rack.
Refer to Table B-5 to determine the proper wire lug for the connection to the
batteries, based on the wire size and battery manufacturer. One column lists
the selection for Dynasty and the other lists the selection for Absolyte IIP.
Table B-4 Power Supply Rack connection lugs
Wire size Cabinet lug Crimp tool Lug P/N †
4/0 double 3/8” hole, 1” center TBM5-S 54212
250 MCM double 3/8” hole, 1” center TBM8-S 54213
350 MCM double 3/8” hole, 1” center TBM8-S 54215
500 MCM double 3/8” hole, 1” center TBM8-S 54218
† All part numbers are Thomas & Betts.
Table B-5 Battery connection lugs
Wire size
Lug
color
Dynasty Absolyte IIP
Description P/N Description P/N
4/0 purple double 3/8” hole,
1” center
54212 single 1/2” hole 54170
250 MCM yellow double 3/8” hole,
1” center
54215 single 1/2” hole 54113
350 MCM red double 3/8” hole,
1” center
54218 single 1/2” hole 54115
500 MCM brown double 3/8” hole,
1” center
54220 single 5/8” hole 54118
