Chapter 4 Installation Gen 3 Site Controller System Manual
Intercabling Connections
4-16 68P80801E30-A 5/1/2002
13-18 Channel 800 MHz GEN 4 RFDS
Expansion Site Cables
Table 4-12 lists the required cables for a 13-18 channel GEN 4 RFDS
expansion site.
Table 4-12 13-18 Channel 800 MHz GEN 4 RFDS Expansion Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to Main RF Cabinet
0112004Z29 Ethernet 1 Main RF Cabinet to Expansion RF
Cabinet #1
0112004Z29 Ethernet 1 Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
0112004Z29 5 MHz/1 PPS 1 Site controller to Main RF Cabinet
0112004Z29 5 MHz/1 PPS 1 Main RF Cabinet to Expansion RF
Cabinet #1
0112004Z29 5 MHz/1 PPS 1 Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
3084225N42 Alarms 1 EAS/EAS2 to Main RF Cabinet
3084225N42 Alarms 1 EAS/EAS2 to Expansion RF
Cabinet #1
3084225N42 Alarms 1 EAS/EAS2 to Expansion RF
Cabinet #2
0112004B24 Receive
Expansion Cables
3 Main RF Cabinet to Expansion RF
Cabinet
