Chapter 4 Installation Gen 3 Site Controller System Manual
Intercabling Connections
4-14 68P80801E30-A 5/1/2002
9-12 Channel Duplex Hybrid Expansion Site
Cables
Table 4-9 lists the required cables for a 9-12 channel duplex hybrid
expansion site.
800 MHz GEN 4 Duplexed RFDS and 900 MHz Duplexed RFDS Intercabinet Cabling
Intercabling between the Control Cabinet and the RF Cabinets for systems
equipped with 900 MHz Duplexed or 800 MHz GEN 4 RF Distribution
Systems is listed below. Choose the appropriate table below, then refer to the
appropriate instructions for connecting the required intercabling.
Table 4-9 9-12 Channel Duplex Hybrid Expansion Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to Main RF Cabinet
0112004Z29 Ethernet 1 Main RF Cabinet to Expansion RF
Cabinet #1
0112004Z29 Ethernet 1 Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
0112004Z29 5 MHz/1 PPS 1 Site controller to Main RF Cabinet
0112004Z29 5 MHz/1 PPS 1 Main RF Cabinet to Expansion RF
Cabinet #1
0112004Z29 5 MHz/1 PPS 1 Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
3084225N42 Alarms 1 EAS/EAS2 to Main RF Cabinet
3084225N42 Alarms 1 EAS/EAS2 to Expansion RF
Cabinet #1
3084225N42 Alarms 1 EAS/EAS2 to Expansion RF
Cabinet #2
