Making custom cables
If custom Ethernet or 5 MHz cables must be locally manufactured, use the
part numbers listed in Table B-7 for ordering the required materials.
Table B-8 lists the part numbers for custom alarm cables.
Table B-9 lists the part numbers for custom PCCH cables.
Table B-7 Parts for Ethernet and 5 MHz cables
Description Qty. P/N
connector, BNC male as required 2884967D01
cable, RG400 as required 3084173E01
NOTE: All part numbers are Motorola.
Table B-8 Parts for alarm cables
Description Qty. P/N
connector, 8-pin modular as required 2882349V01
cable, 8-wire as required locally procured
NOTE: All part numbers are Motorola.
Table B-9 Parts for extending PCCH redundancy control cables
Description Qty. P/N
186” long, PCCH redundancy control cable 1 per
Cabinet
3082070X01
8-pin male Telco to 8-pin male Telco
extension cable, length: as needed
as required locally procured
modular, 8-pin female-to-female adaptor as required locally procured
NOTE: Motorola does not guarantee proper operation of system if longer PCCH cable
is used.
All part numbers are Motorola.
