AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 99
Appendix B: Special Zone Outputs
B.1 Output Delay Time
B.1.1 What is Output Delay Time?
Purpose
Output Delay Time is a feature that initially causes specific alarm signals to only sound in specific
areas, monitored by qualified persons. This allows delay of the alarm up to 600 seconds after the
start of alarm processing.
•A Output Delay Time (0:00 to 10:00 minutes; Default 1:00 minute) that delays activation
of all outputs with a CBE that includes Special Zone ZF0. Note the following:
–When enabled, the Delays On/Off LED of the keypad will be lit. Once the delay timer
has expired, a reset has occurred, or the delay function has been disabled using the
Delays On/Off softkey of the keypad, the LED will extinguish.
–A system reset will reset the timer until another alarm occurs activating Special Function
ZF0.
–Signal Silence does not affect the activation of delayed outputs. Once the timer has
expired, all delayed outputs will activate. Any subsequent Signal Silence will silence all
silenceable delayed outputs.
An illustration of Output Delay timing.
Figure B.1 Output Delay Time
The control panel delays activation of outputs containing ZF0 in their zone maps for all alarm
initiating devices that contain ZF0 in their CBE list. A subsequent alarm will abort the Output
Delay Time and execute CBE lists.
Notes on using ZF0
• The Output Delay Time countdown can be stopped by pressing the SYSTEM RESET key
before the timer expires or pressing the Delays On/Off softkey.
• Program zone ZF0 to participating inputs and outputs. The Output Delay Time will not
delay activation of zones programmed to delayed outputs.
• The Output Delay Time only operates when activated from initiating devices that contain
ZF0 in their CBE list.
Restrictions on using ZF0
• Do not include ZF0 in the CBE list for a releasing device.
• Do not include ZF0 in the CBE list for any monitor module that connects to a device other
than an automatic fire detector.
• Do not include ZF0 in the CBE list of any modules used with Smoke Control.
• Do not include ZF0 in the CBE list for a Manual Call Point device when programming the
panel for compliance with AS7240.2.
