PrealarmProgram Panel Program
The logical sequence for initial programming is to program the panel parameters first, then to
program the individual points through autoprogramming and/or point programming.
3.2 Panel Program
Panel programming provides the means to change settings for the panel system as a whole, as well
to address and program annunciator points.
3.2.1 Panel Program Menu (1)
Press the Panel Program Menu for the following choices.
Figure 3.2 Panel Program Menu 1 Screen
3.2.2 Network Parameters
Press the Network Parameters soft key on Panel Program Menu 1 to bring up the following screen.
If the panel will operate as a standalone unit and not part of a network, the node label is the only
field that needs to be entered: it is the label that appears as part of the System Normal message.
Figure 3.3 Network Parameters Screen
PANEL PROGRAM MENU
NETWORK PARAMETERS LCD DISPLAY
NETWORK MAPPING ACS PROGRAMMING
PANEL SETTINGS SUPERVISION
PANEL TIMERS MORE
BACK
Network Mapping option is only available when Network Display Mode is enabled.
NETWORK PARAMETERS
NODE NUMBER: 000
NODE LABEL:
LAKEVIEW GENERAL HOSPITAL
STYLE: OPEN IP ACCESS
CH A. THRESHOLD: HIGH ACCEPT
CH B. THRESHOLD: LOW BACK
To Next Page
