124 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Type Codes Type Codes for Input Devices
F.4.3 Type Codes for Monitor Modules
Following is a list of monitor module Type Codes, which can be used to change the function of a
monitor module point.
Type Code Point Type
Point Characteristics
Latching
(Y
= yes
N = no)
Activates
CBE
Device Function
MONITOR fire alarm Y Y Alarm-monitoring device
NC MONITOR fire alarm Y Y Alarm monitoring device, where an open circuit = active.
MCP fire alarm Y Y Manual fire-alarm-activating device
SMOKE CONVEN fire alarm Y Y Indicates activation of a conventional smoke detector. An FZM-1
must be used for alarm verification of a two-wire conventional
detector.
WATERFLOW fire alarm Y Y Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Y Indicates supervisory condition for activated waterflow switch
ALARM DEV FLT fault N N Used for monitoring audio equipment (use fault zones for
activations)
FMM 4-20 user-
programmable
Y Y Monitors 4-20 mA industrial sensors.
LATCH SUPERV supervisory Y Y Indicates latching supervisory condition
NC SUP L supervisory Y Y Indicates latching supervisory condition, where an open
circuit = active.
TRACK SUPERV supervisory N Y Monitors for waterflow tamper switches for alarm points
NC SUP T supervisory N Y Indicates tracking supervisory condition, where an open
circuit = active.
SPRINKLR SYS supervisory Y Y Monitors a waterflow device
TAMPER supervisory Y Y Indicates activation of tamper switch
ACK SWITCH non-alarm N N Performs Acknowledge function
FIRE CONTROL non-alarm N Y Monitors non-fire activations
NON FIRE non-alarm N Y Monitors non-fire activations
NC NON FIRE non-alarm N Y Monitors non-fire activations, where an open circuit = active.
POWER MONITR fault
*
N N Monitors main and auxiliary power supplies (use fault zones for
activations)
RESET SWITCH non-alarm N N Performs Reset function
SIL SWITCH non-alarm N N Performs Signal Silence function
DISABLE MON disable N N When this point activates it will create a disable on the panel for that
point. No CBE generated. Modules can not be disabled via ACS,
Alter Status, or over the network.
FAULT MON fault N N Monitors fault inputs (use fault zones for activations)
Blank fire alarm Y Y Monitors for a device with no description
HEAT DETECT fire alarm Y Y Monitors for conventional heat detector
ABORT SWITCH non-alarm N Y Provides an abort function through a monitor module (connected to
an abort station) for a releasing zone.
MAN RELEASE fire alarm
†
Y Y Provides a manual release through a monitor module (connected to
a pull station) for a releasing zone
MAN REL DELAY fire alarm
*
Y Y Provides a manual release with a 10-second delay through a
monitor module (connected to a pull station) for a releasing zone
SECOND SHOT fire alarm
*
Y Y Provides a second manual release through a monitor module
(connected to a pull station) for a releasing zone
HAZARD ALRT non-fire N Y Monitors for a hazard alert
WEATHER ALRT non-fire N Y Monitors for a weather alert
PROCESS MON critical process Y Y Monitors for a critical process
PROCMON AUTO critical process N Y Monitors for a critical process
CO MONITOR CO alarm Y Y Monitors conventional CO detectors for a CO alarm condition.
ECS/MN MON alarm Y Y Monitors mass notification devices for alarm activation.
ECS/MN SUPT supervisory N Y Tracking supervisory monitor for mass notification devices.
ECS/MN SUPL supervisory Y Y Latching supervisory monitor for mass notification devices.
ECS/MN TMON fault N Y Fault monitor for mass notification devices.
RF GATEWAY non-alarm N Y Provides communication between wireless devices and the fire
panel
Table F.2 Type Codes for Monitor Modules (1 of 2)
