68 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
PrealarmProgram Delete Program
3.4.7 Audio Point Programming
When DVC or DAA is selected from the Point Program menu, the Audio Volume Control menu
appears.
Figure 3.56 Audio Point Programming Menu Screen
Soft Keys
MASTER VOLUME: This field can set the volume for all audio outputs at the DVC node. When the
audio amplifier point is set to 00, as it is in
Figure 3.56, the setting affects all audio outputs on the
DVC node (this includes all outputs on its DAAs). When a specific DAA point is entered at the
point program menu (for example, N078AA01
) the MASTER VOLUME setting will apply to the
audio outputs at that DAA (the DAA with its address set to 01). Set this field to any volume setting
from 0 (off) to 15 (high). Default: 15
AUXILIARY VOLUME: This field sets the volume for DVC inputs AUXA (background music from
various sources or a telephone paging source) and AUXB (AMG-1 input). The field does not appear if
a specific DAA address has been entered. The DAAs have onboard volume control for AUX A and
AUXB inputs. Set this field to any volume setting from 0 (off) to 15 (high). Default: 15.
ACCEPT: Press to program the displayed volume.
3.5 Delete Program
Press the DELETE PROGRAM MENU at the PROGRAM/ALTER STATUS MENU menu to
display the screen below.
