16 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Main Menu and Event Counts Screen The Main Menu
Aborting Walk Test
When the “Abort” option is selected, the fire panel will evaluate the system to see if any devices
remain in the “
ACTIVE” state. This screen appears when there are active devices that remain
when aborting Walk Test:.
Figure 2.12 Active Device Alert Screen
Soft Keys
YES: Press this key to exit Walk Test with the devices remaining active. Once Walk Test is exited,
the fire panel will act as if the devices are newly activated and respond accordingly.
NO: Press this key to remain in Walk Test. This will provide the opportunity to clear the active
devices.
2.1.4 History Display (History Select Screen)
The History Select screen allows the user to select a type of history file to view, and to set time/date
or point range viewing parameters.
Refer to this panel’s operations manual for an illustration and description of History Display.
2.1.5 Read Status
Pressing the Read Status soft key brings up screens to view the present status of points, zones, and other
system information. Refer to this panel’s operations manual for a full description of Read Status.
2.1.6 Program/Alter Status
Pressing the Program/Alter Status soft key brings up screens for panel programming, point
programming, autoprogramming, clear programming, altering the status of points, walk test, and
other information. Refer to
Sections 3 and 4 for a full description of Program/Alter Status.
2.1.7 Printer Functions
Pressing the Printer Functions soft key brings up screens to print reports. Refer to this panel’s
operations manual for a description of Printer Functions. This key will appear only if a printer
operation has been selected. Refer to
“Supervision” on page 39 for selection information.
To Next Page
