128 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Appendix G: System Faults
Table G. 1 is a list of System Faults that could occur during the course of FACP operation. The
System Fault Name column is the text that displays in the system fault message. The System Fault
Index is the number associated with the fault in FACP memory. It is the number that can be used as
an argument in a Fault Equation.
System
Fault
Index
System Fault Name
System
Fault
Index
System Fault Name
System
Fault
Index
System Fault Name
System
Fault
Index
System Fault Name
0 GROUND FAULT 61 ANNUN 24 FAULT 197 CLOSED POS LOOP 8 390 REMOTE DISPLAY 4 FAULT
1 AC FAIL 62 ANNUN 24 NO ANSWER 198 CLOSED POS LOOP 9 391 REMOTE DISPLAY 4 NO ANSWER
2 BATTERY 63 ANNUN 25 FAULT 199 CLOSED POS LOOP 10 392 REMOTE DISPLAY 5 FAULT
3 CLOSED POS LOOP 1 64 ANNUN 25 NO ANSWER 200 RESERVED 393 REMOTE DISPLAY 5 NO ANSWER
4 CLOSED POS LOOP 2 65 ANNUN 26 FAULT 201 BUZZER OFF-LINE 394 REMOTE DISPLAY 6 FAULT
5 CORRUPT LOGIC EQUAT 66 ANNUN 26 NO ANSWER 202 RESERVED 395 REMOTE DISPLAY 6 NO ANSWER
6 LCD80 SUPERVISORY 67 ANNUN 27 FAULT 203 RESERVED 396 REMOTE DISPLAY 7 FAULT
7 EPROM ERROR 68 ANNUN 27 NO ANSWER 204 RESERVED 397 REMOTE DISPLAY 7 NO ANSWER
8 INTERNAL RAM ERROR 69 ANNUN 28 FAULT 205 RESERVED 398 REMOTE DISPLAY 8 FAULT
9 EXTERNAL RAM ERROR 70 ANNUN 28 NO ANSWER 206 PRINTER PAPER OUT 399 REMOTE DISPLAY 8 NO ANSWER
10 PROGRAM CORRUPTED 71 ANNUN 29 FAULT 207 PRINTER OFF LINE 400 REMOTE DISPLAY 9 FAULT
11 NO DEV INST ON L1 72 ANNUN 29 NO ANSWER 208 RESERVED 401 REMOTE DISPLAY 9 NO ANSWER
12 PANEL DOOR OPEN 73 ANNUN 30 FAULT 209 RESERVED 402 REMOTE DISPLAY 10 FAULT
13 AUXILIARY FAULT 74 ANNUN 30 NO ANSWER 210 MANUAL MODE ENTERED 403 REMOTE DISPLAY 10 NO ANSWER
14 RESERVED 75 ANNUN 31 FAULT 211 NCM COMM LOSS 404 REMOTE DISPLAY 11 FAULT
15 ANNUN 1 FAULT 76 ANNUN 31 NO ANSWER 212 OPEN SHORT A LOOP 1 405 REMOTE DISPLAY 11 NO ANSWER
16 ANNUN 1 NO ANSWER 77 ANNUN 32 FAULT 213 OPEN SHORT B LOOP 1 406 REMOTE DISPLAY 12 FAULT
17 ANNUN 2 FAULT 78 ANNUN 32 NO ANSWER 214 OPEN SHORT A LOOP 2 407 REMOTE DISPLAY 12 NO ANSWER
18 ANNUN 2 NO ANSWER 79 NETWORK FAIL PORT A 215 OPEN SHORT B LOOP 2 408 REMOTE DISPLAY 13 FAULT
19 ANNUN 3 FAULT 80 NETWORK FAIL PORT B 216 OPEN SHORT A LOOP 3 409 REMOTE DISPLAY 13 NO ANSWER
20 ANNUN 3 NO ANSWER 81 NETWORK FAILURE 217 OPEN SHORT B LOOP 3 410 REMOTE DISPLAY 14 FAULT
21 ANNUN 4 FAULT 82 ADV WALK TEST 218 OPEN SHORT A LOOP 4 411 REMOTE DISPLAY 14 NO ANSWER
22 ANNUN 4 NO ANSWER 83 CHARGER FAIL 219 OPEN SHORT B LOOP 4 412 REMOTE DISPLAY 15 FAULT
23 ANNUN 5 FAULT 84 GROUND FAULT LOOP 2 220 OPEN SHORT A LOOP 5 413 REMOTE DISPLAY 15 NO ANSWER
24 ANNUN 5 NO ANSWER 85 CLOSED NEG LOOP 1 221 OPEN SHORT B LOOP 5 414 REMOTE DISPLAY 16 FAULT
25 ANNUN 6 FAULT 86 CLOSED NEG LOOP 2 222 OPEN SHORT A LOOP 6 415 REMOTE DISPLAY 16 NO ANSWER
26 ANNUN 6 NO ANSWER 87 GROUND FAULT LOOP 1 223 OPEN SHORT B LOOP 6 416 REMOTE DISPLAY 17 FAULT
27 ANNUN 7 FAULT 88 RESERVED 224 OPEN SHORT A LOOP 7 417 REMOTE DISPLAY 17 NO ANSWER
28 ANNUN 7 NO ANSWER 89 RESERVED 225 OPEN SHORT B LOOP 7 418 REMOTE DISPLAY 18 FAULT
29 ANNUN 8 FAULT 90 PROG MODE ACTIVATED 226 OPEN SHORT A LOOP 8 419 REMOTE DISPLAY 18 NO ANSWER
30 ANNUN 8 NO ANSWER 91 LOADING...NO SERVICE 227 OPEN SHORT B LOOP 8 420 REMOTE DISPLAY 19 FAULT
31 ANNUN 9 FAULT 92 BASIC WALK TEST 228 OPEN SHORT A LOOP 9 421 REMOTE DISPLAY 19 NO ANSWER
32 ANNUN 9 NO ANSWER 93 NFPA 24HR REMINDER 229 OPEN SHORT B LOOP 9 422 REMOTE DISPLAY 20 FAULT
33 ANNUN 10 FAULT 94 NVRAM BATT FAULT 230 OPEN SHORT A LOOP 10 423 REMOTE DISPLAY 20 NO ANSWER
34 ANNUN 10 NO ANSWER 95-104 RESERVED 231 OPEN SHORT B LOOP 10 424 REMOTE DISPLAY 21 FAULT
35 ANNUN 11 FAULT 105 CLOSED ON LOOP 3 232 RESERVED 425 REMOTE DISPLAY 21 NO ANSWER
36 ANNUN 11 NO ANSWER 106 RESERVED 233 CLOSED SHORT LOOP 1 426 REMOTE DISPLAY 22 FAULT
37 ANNUN 12 FAULT 107 RESERVED 234 CLOSED SHORT LOOP 2 427 REMOTE DISPLAY 22 NO ANSWER
38 ANNUN 12 NO ANSWER 108 MAN EVAC INITIATED 235 CLOSED SHORT LOOP 3 428 REMOTE DISPLAY 23 FAULT
39 ANNUN 13 FAULT 109 MAN EVAC RECEIVED 236 CLOSED SHORT LOOP 4 429 REMOTE DISPLAY 23 NO ANSWER
40 ANNUN 13 NO ANSWER 110-175 RESERVED 237 CLOSED SHORT LOOP 5 430 REMOTE DISPLAY 24 FAULT
41 ANNUN 14 FAULT 176 GROUND FAULT LOOP 3 238 CLOSED SHORT LOOP 6 431 REMOTE DISPLAY 24 NO ANSWER
42 ANNUN 14 NO ANSWER 177 GROUND FAULT LOOP 4 239 CLOSED SHORT LOOP 7 432 REMOTE DISPLAY 25 FAULT
43 ANNUN 15 FAULT 178 GROUND FAULT LOOP 5 240 CLOSED SHORT LOOP 8 433 REMOTE DISPLAY 25 NO ANSWER
44 ANNUN 15 NO ANSWER 179 GROUND FAULT LOOP 6 241 CLOSED SHORT LOOP 9 434 REMOTE DISPLAY 26 FAULT
45 ANNUN 16 FAULT 180 GROUND FAULT LOOP 7 242 CLOSED SHORT LOOP 10 435 REMOTE DISPLAY 26 NO ANSWER
46 ANNUN 16 NO ANSWER 181 GROUND FAULT LOOP 8 243 NCM COM LOSS 436 REMOTE DISPLAY 27 FAULT
47 ANNUN 17 FAULT 182 GROUND FAULT LOOP 9 244-249 RESERVED 437 REMOTE DISPLAY 27 NO ANSWER
48 ANNUN 17 NO ANSWER 183 GROUND FAULT LOOP 10 250 SELF TEST FAILED 438 REMOTE DISPLAY 28 FAULT
49 ANNUN 18 FAULT 184 CLOSED NEG LOOP 3 251 NETWORK INCOMPATIBILITY 439 REMOTE DISPLAY 28 NO ANSWER
50 ANNUN 18 NO ANSWER 186 CLOSED NEG LOOP 5 252 RESERVED 440 REMOTE DISPLAY 29 FAULT
51 ANNUN 19 FAULT 187 CLOSED NEG LOOP 6 253 NETWORK MAP LIMIT EXCEEDED 441 REMOTE DISPLAY 29 NO ANSWER
52 ANNUN 19 NO ANSWER 188 CLOSED NEG LOOP 7 254 INVALID NODE TYPE 442 REMOTE DISPLAY 30 FAULT
53 ANNUN 20 FAULT 189 CLOSED NEG LOOP 8 255 DISPLAY NODE LIMIT EXCEEDED 443 REMOTE DISPLAY 30 NO ANSWER
54 ANNUN 20 NO ANSWER 190 CLOSED NEG LOOP 9 256-383 RESERVED 444 REMOTE DISPLAY 31 FAULT
55 ANNUN 21 FAULT 191 CLOSED NEG LOOP 10 384 REMOTE DISPLAY 1 FAULT 445 REMOTE DISPLAY 31 NO ANSWER
56 ANNUN 21 NO ANSWER 192 CLOSED POS LOOP 3 385 REMOTE DISPLAY 1 NO ANSWER 446 REMOTE DISPLAY 32 FAULT
57 ANNUN 22 FAULT 193 CLOSED POS LOOP 4 386 REMOTE DISPLAY 2 FAULT 447 REMOTE DISPLAY 32 NO ANSWER
58 ANNUN 22 NO ANSWER 194 CLOSED POS LOOP 5 387 REMOTE DISPLAY 2 NO ANSWER 448 SYSTEM INITIALIZATION
59 ANNUN 23 FAULT 195 CLOSED POS LOOP 6 388 REMOTE DISPLAY 3 FAULT 449-502 RESERVED
60 ANNUN 23 NO ANSWER 196 CLOSED POS LOOP 7 389 REMOTE DISPLAY 3 NO ANSWER 503 SOFTWARE MISMATCH
Table G.1 System Fault Names and Codes (1 of 2)
