42 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
PrealarmProgram Panel Program Menu (2)
Soft Keys
WEEKLY OCCUPANCY SCHEDULE: Press this soft key to toggle between schedules 1 - 10. A
value of zero indicates no schedule.
ACCEPT: Press this to save changes made on the screen.
3.3.3 Loop Configuration
This screen displays when the LOOP CONFIGURATION soft key is pressed at the PANEL
PROGRAMMING MENU 2 screen. Here the programmer chooses one of the ten possible SLC loops
for further definition.
Figure 3.26 Loop Configuration Screen
Soft Keys
LOOP SELECTION: Pressing this soft key will invoke the cursor at the underlined field. Enter the
loop number desired (01 through 10) in the yy of the Lyy format.
NEXT/PREVIOUS SELECTION: Press either key to go forward or back through the loop
selections.
ACCEPT: Press to proceed to the Loop Point Programming screen.
