C.4.2 To Test Detectors Set Below 1.63% Obscuration per Metre
When using alarm sensitivities below 1.63% obscuration per metre, it is recommended to perform a
90-day test to ensure that the detector environment is suitable for the higher sensitivity setting. Test
each detector planned to operate below 1.63%/m obscuration as follows:
1. Set the detector as follows:
2. Operate detectors continuously for 90 days with all environmental factors (such as,
temperature, humidity, air flow, occupancy, and so on) similar to the intended application for
the detectors. Record all events for each tested detector with an electronic History buffer or a
printout.
3. If the test results show no alarms or pre-alarms for the tested detectors, reprogram the fire
alarm system to set the Alarm sensitivity to the more sensitive Pre-Alarm level of the test.
C.5 Detector Status Display
C.5.1 Detector Maintenance Display
Should the panel detect a low chamber value or maintenance condition with a detector, it will
generate a point fault as described in the operations manual for this panel. The following Read
Status screen displays detector information that applies to the state of the smoke detector. It can be
reached with the following commands, starting at the Main Menu screen:
• Press MAIN MENU
• Press READ STATUS
• Press READ STATUS POINT SELECT (enter the detector point address)
* Detectors are suitable for open area protection within the listed air velocity range. Typically, this range is 0 - 20.32 ms
-1
for photoelectric
detectors and 0 - 6.096 ms
-1
for ionization detectors. Be sure to confirm this range before installing the detector by referring to the
manufacturer’s installation instructions.
† 3.24% max. on CLIP. Larger figures may display.
‡ The use of alarm sensitivities below 1.63% obscuration per metre requires a 90 day test to ensure that the environment for the detectors is suitable for the
higher sensitivity setting. (Refer to
“To Test Detectors Set Below 1.63% Obscuration per Metre” on page 109.)
** Refer to the beam detector manual to determine the alarm settings: they are a function of the distance between the detector and its reflector.
There is no Prealarm for beam detectors in CLIP mode.
†† AL:6 and PA:6 are not available in CLIP mode.
‡‡ Within the 10 minute signature confirmation delay period, if there is a detection of another fire signature (Carbon Monoxide, Infrared
or Thermal) it overrides the 10 minute confirmation time.
Step Action
1 Initially set to the 1.63% obscuration per metre Alarm level.
2 Set the Pre-Alarm level to the desired final Alarm sensitivity.
3 Set the Pre-Alarm to Alert mode (non-latching).
