AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 111
Detector Status Display Intelligent Sensing Applications
C.5.3 To Interpret a Detector Status Display or Maintenance Report
The Detector Read Status Screen and Detector Maintenance Report provides the same information
(such as Device Status, Peak Value) about a detector. This section contains descriptions of each
item that appears in a Detector Read Status Screen or a Detector Maintenance Report.
Display Information
Lines 1- 4 - This could display any current event message, or, as in this example, the System
Normal message
Line 5 - Screen title and the address of the point being read
The area between the separator lines, lines 6-14, shows all information concerning the selected
point, which is L03D052 in the above example.
Line 6 - Line 6 displays two statistics that display for inputs (detectors and modules) and zones; in
the above example they are:
AUTOMATIC INACTIVE
The first field displays the point control. There are three designations that could appear in this field
The second field displays the point status. There are two designations that could appear in this field.
The device is a detector (an input device) so by referring to the descriptions below, it can be
determined that the point is in a normal state.
Inputs: (detectors, monitor modules, zones)
If the point is not in fault or disabled, and the point is automatically controlled by the panel, the
display will be one of the following:
AUTOMATIC INACTIVE
AUTOMATIC
ACTIVE
AUTOMATIC
PREALARM
If the point is disabled, the display will be one of the following. The Fault Status field will appear if
the point is in fault.
DISABLED INACTIVE <Fault Status>*
DISABLED ACTIVE <Fault Status>*
DISABLED PREALARM <Fault Status>*
If the point is in fault, the display will read:
FAULT INACTIVE <Fault Status>*
FAULT ACTIVE <Fault Status>*
Point Control
Designation
Description
AUTOMATIC
The point is being controlled automatically by the panel.
DISABLED
The point has been forced into a disabled state by an outside source.
FAULT
The point is in a fault state and is no longer functioning automatically.
Point Status
Designation
Description
INACTIVE
The point is currently reporting no events.
ACTIVE
The point is currently in an off-normal status.
PREALARM
The point is currently in a prealarm status.
