8 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Main Menu and Event Counts Screen The Main Menu
2.1.2 Disable/Enable
Pressing the DISABLE/ENABLE soft key on the Main Menu brings up the point select screen for
disabling a device. From this screen, the user can disable a device installed on the system.
Disable/Enable Point Selection
.
Figure 2.3 Point Select for Disable/Enable Screen
Soft Keys
POINT SELECT: Press this soft key to identify the type of point to disable/enable: the choices
that will appear in parentheses next to the point format are DETECTOR, MODULE, VESDA, BELL
CKT, ZONE, LOGIC ZONE, DAL SPEAKER CKT, or DAL ALL CKTS. Enter the address of the
point using the keyboard. If there is an event in the display area, that address will be the default. If
no event is present, the default format will be that of a detector.
Disable/Enable
A point can be disabled or enabled using this screen. Once a point has been selected, press the
ACCEPT soft key display the following.
Figure 2.4 Disable/Enable Screen
