AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 47
Point Program PrealarmProgram
ACCEPT: Press to progress to the appropriate screen, based on the type of point selected.
NEXT/PREVIOUS SELECTION: Press to scroll backward or forward to the next or previously
installed point.
3.4.1 Detector Point
This screen displays when a detector is chosen at the POINT PROGRAM menu (see Figure 3.31 on
page 46).
Figure 3.32 Detector Point Programming Screen
The point address is displayed in line 3 of this screen. Existing point information is displayed in the
fields.
Soft Keys
TYPE: Press this soft key to scroll through the point type choices: stop at the appropriate selection.
If a new point is being added, no other field will be displayed until TYPE: is entered and the
ACCEPT soft key is pressed. At this point, the rest of the fields will appear.
FLASHSCAN CODE LABEL: Press to scroll through a list of FlashScan Codes. Stop when the
appropriate label appears (
Table F.4 on page 126 for codes and descriptions). If the detector is not a
FlashScan type, choose NONE.
MODULE LyyMzzz L = Loop, yy = Loop number (1-10)
M = Module, zzz = Module address (1-159)
ZONE Zyyy Z = Zone, yyy = Zone number (0-999)
LOGIC ZONE ZLyyyy ZL = Logic Zone, yyyy = Logic Zone number(1-1000)
ACS BOARD Axx + Custom Label A = Annunciator, Custom label
RELEASE ZONE Ryy R = Releasing Zone, yy = Releasing Zone number (00-09)
FAULT ZONE ZTyyy ZT = Fault Zone, yyy = Fault Zone number (1-100)
AMPLIFIER NxxxAAyy N = Node, xxx = DVC or DVC-EM Node number, AA = DAA Audio Amplifier,
yy
= DAA address (01 through 32).
Note: When yy=00, the address format is the DVC or DVC-EM address.
Type Address Format
Table 3.7 Address Formats (2 of 2)
DETECTOR POINT PROGRAMMING
L03D123
TYPE:
SMOKE (PHOTO)
FLASHSCAN TYPE: PHOTO
POINT LABEL:
MORE
ACCEPT
ZONE MAP:
Z003, Z104, Z105, Z106, Z107,
Z110, Z114, Z115, Z116, Z117 BACK
Zone Map position 6
Zone Map position 10Zone Map
position 1
(primary zone)
