5.2 Power-up Screen
The Power-up screen appears when the panel is powering up. A series of self-tests are performed
internally: the tests and the results of the tests appear on the screen as they are completed.
Figure 5.6 Self Test Screen
5.3 Bootloader Screen
This screen is used for LCD-160 and Loop downloads. To display this screen, press the RESET key
during the entire power-up self-testing process, then release the key.
Figure 5.7 Bootloader Menu Screen
REBOOT: Press this soft key to reboot the panel, and exit the bootloader screen.
LOOP DOWNLOAD: Press this soft key to display the Loop Download Menu screen.
BOOT: 010.000.025 APP: 010.000.041
SELF TEST
RAM TEST: PASS BOOT CRC: PASS
NVRAM TEST: PASS APP CRC: PASS
RTC TEST: PASS DBASE CRC: PASS
KEYPAD : PASS LANG CRC: PASS
COMM 1 : PASS LCM CRC: PASS
COMM 2 : PASS
COMM 3 : PASS
FAULT
LOADING..NO SERVICE
LAKEVIEW GENERAL HOSPITAL
BOOTLOADER
11:58:45A WED JAN 19, 2011
REBOOT
LOOP DOWNLOAD
