PrealarmProgram Panel Program
Figure 3.18 LCD Display Screen
Soft Keys
BRIGHTER: Press this soft key to increase contrast. The intensity will increase by approximately
5% with each press of the key.
DARKER: Press this soft key to decrease contrast. The intensity will decrease by approximately
5% with each press of the key.
BACKLIGHT: Press this soft key to select one of the following backlighting options: ON EXCEPT
AC FAIL, OFF, or ON. When ON EXCEPT AC FAIL is selected, the backlight will turn off when
the power supply experiences AC failure. Default: ON
DEFAULT: Press to select the factory default setting (40%).
CURRENT: Press to select the intensity that was in effect when the screen was accessed.
ACCEPT: Line 5 (which displays LCD INTENSITY: 50% in the figure above) will change
value when the INTENSITY soft keys are pressed. Press ACCEPT to save the desired setting.
3.2.8 ACS Programming
An ACS device is a remote device used by the panel to annunciate certain system messages, and/or
to act with limited commands. A total of 32 annunciator devices may be present on the EIA-485
ACS circuit; however, some devices have associated expander devices, and an AFP-3030 ACS
circuit can accommodate up to 3,072 annunciator points. The ACS Programming and ACS Point
Programming screens in this section allow the user to define the mapping and functional mode of
these devices and points. Each annunciator board may be labelled using the ACS Label Menu.
(Refer to
Section 3.4.6, “Annunciator Board Label”, on page 66).
