82 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Alter Status Control On/Off Point Select
Soft Keys
POINT: Press this soft key to enter the point address or general zone number (except Z000) to be
forced on or off.
NEXT/PREVIOUS SELECTION: Press to progress to the next or previous point on the loop, or
the next or previous general zone.
ACCEPT: Press to continue to the Control On or Control Off screen.
4.5.1 Control Off
One of the following two screens will display when a point or general zone is selected and accepted
in the previous screen.
If the selected point or zone is active, the Control Off screen will appear.
Figure 4.12 Control Off Screen
Soft Keys
FORCE OFF: Press this soft key to change the state of the control module or general zone from
AUTOMATIC ACTIVE to AUTOMATIC INACTIVE.
NOTE: A module with a releasing Type ID can not be forced.
