INTELLIGENT PDU USER MANUAL
Appendix A: Sensor Configuration
Door Switch Sensor
Door Switch Sensor is designed to send an alarm or notification signal when the door
on which it is installed had been opened more than 10mm. This provides added
security. The door switch can be configured to alert when the door is opened, alert
when the door is closed, or the alerts can be disabled.
Figure 87: Door Switch Sensor Configuration
Note: The Door Switch Sensor is only designed to connect to a Panduit PDU.
Connecting it to another device may result in damage.
Dry Contact Input Sensor (side panel switch)
The dry contact sensor can be configured to alert when the when the contact is opened,
alert when the contact is closed, or the alerts can be disabled.
