INTELLIGENT PDU USER MANUAL

Number

Icon

Description

click user guide and

license to ask for help.

This icon shows who is

logged in (user or admin).

Account passwords can be

changed, and user

accounts managed

through this page.

Screen Resize Due to Multiple PDU Configuration

Resizing a Screen

Multiple PDUs can now cause the user to resize the screen to fit the information on the

dashboard due to the update.

Figure 9 - Resized Dashboard Screen
