Data Arrangement
Data
Length
Output Example
ECO 3 byte QSP
1 MDUcom-PRG 8 byte =01Y
2 MDUcom-DATA_TBL 8 byte =01Y ’ ’ ’ ’
3 SQ_LSI-PRG 4 byte =01Y
4 SQ_LSI-PIC_TBL 8 byte =01Y ’ ’ ’ ’
5 SQ_LSI-SEQ_DATA 4 byte =01Y
6
CS
Reserved 8 byte
∗∗∗∗∗∗∗∗
2 Byte 2 byte A3
Command
Format
Effective Operation
Modes
Function Remarks
[QSP] Every Time Output of status Return data: 3 (ECO) + 40 (DATA) + 2 (CS) = 45 Byte
[5] QSP (SUB VERSION OF THE PANEL SECTION)
The command QSP is for acquiring sub version data on software of the panel.
