Remov
e the four riv
ets.
1
Pull the lower part of the front bezel (509TVU)
toward y
ou and out.
2
Remov
e the front bezel (509TVU), by pulling
it upward.
3
Front Bezel (509TVU)
6
3
2
1
T
urn it not to press the r
ivet.
(Because when the rivet presses, fit in once again.)
Rivet
F
ront bezel (509TVU)
LED Assy
IR Assy
RLS Assy
F
ront side
When assembling the front bez
el,
tighten this rivet first.
