[2] PANEL FACTORY (+)
This is the menu screen for the adjustment of the panel. Data acquisition and value adjustment can be performed for
the following items:
No. Indication Description of functions
[2-1] PANEL INFORMATION Data, such as the version of the microcomputer of the panel, product serial number, and
statuses of EEPROM for adjustment values for the main unit and for backup, are
displayed.
[2-2] PANEL WORKS Operation data, such as accumulated pulse-meter count, accumulated hour-meter
count, accumulated power-on count, and the temperature detected by the sensor, are
displayed.
[2-3] POWER DOWN The power-down history is displayed.
[2-4] SHUT DOWN
The shutdown history of the panel section is displayed.
[2-5] PANEL-1 ADJ (+) Settings of the driving voltage and AM radio prevention can be performed.
[2-6] PANEL-2 ADJ (+) White balance and ABL (power consumption) for the panel can be set.
[2-7] PANEL FUNCTION (+)
Setting of the panel-degradation correction-level and various functions are displayed.
[2-8] ETC. (+)
Copying of backup data, clearing of various settings, and changing of settings for
functions for which setting data are not stored upon last update are performed.
[2-9] RASTER MASK SETUP (+) The mask indication (RASTER) can be set and indicated.
[2-10] PATTERN MASK SETUP (+) The mask indication (PATTERN) can be set and indicated.
[2-11] COMBI MASK SETUP (+) The mask indication (COMBI) can be set and indicated.
