Pioneer PDP-5020FD User Manual

152
PDP-5020FD
1
2 3 4
A
B
C
D
E
F
1
2 3 4
Remove the six screws. (ABA1377)
1
Remove the four screws. (ABA1313)
2
Disconnect the two flexible cables.
3
Lift the Multibase Section to the direction of the arrow.
4
Access to 50F DIGITAL Assy
5
T panel U Assy
Multibase Section
50F DIGITAL Assy
1
1
2
2 2
2
4
3
3
1
1
1
1
Note:
When you remove whole Multibase Section, it is not
necessary to remove T panel U Assy.
Note: The wiring shown in the photo is different from the actual wiring, because the product in the photo is a prototype.
Upon servicing, be sure to restore the original wiring of the unit after repair work.
Note on connection of the flexible cable
This flexible cables requires correct orientation for
connection. Connect the folded side of the cable to the
connector on the DIGITAL Assy, as shown in the photo
below. Reversely connecting the cable will damage
the Assy.
Folded side
DIGITAL Assy
