Pioneer PDP-5020FD User Manual

99
PDP-5020FD
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Data Arrangement
Data
Length
Output Example
ECO 3 byte QS3
1 SERIAL 15 byte - - - - - - - - - - - - - - -
2 HOUR METER 8 byte 00000000
3 TOTAL HR METER 8 byte 00000000
4 PON COUNTER 8 byte 00000000
5 Panel temperature (*1) 5 byte 23.5
6 Reserved (TEMP0 acquisition) 5 byte _ _ _._
7 MAX panel temperature history (*1) 5 byte 78.3
8
CS
Reserved 4 byte
∗∗∗∗
2 Byte 2 byte 94
Command
Format
Effective Operation
Modes
Function Remarks
[QS3] Every Time Output of status Return data: 3 (ECO) + 58 (DATA) + 2 (CS) = 63 Byte
[3] QS3 (OTHER DATA ON THE PANEL)
The command QS3 is for acquiring data on operational information of the panel.
Note
(*1) : Centigrade scale
Data Arrangement
Data
Length
Output Example
ECO 3 byte QS5
1 Color sensor data (Note) 1 byte 2
2 RED data of color sensor 4 byte 0425
3 GREEN data of color sensor 4 byte 2112
4 BLUE data of color sensor 4 byte 5000
5 Reserved 32 byte
∗∗ to ∗∗
CS 2 Byte 2 byte 94
Command
Format
Effective Operation
Modes
Function Remarks
[QS5] Every Time Output of status Return data: 3 (ECO) + 45 (DATA) + 2 (CS) = 50 Byte
[4] QS5 (COLOR SENSOR DATA)
The command QS5 is for acquiring the color sensor information.
Note: The color sensor data is output as the same data as QS2.
