[7] QPW (VIDEO ADJUSTMENT DATA OF THE PANEL)
Data Arrangement
Data
Length
Output
Example
ECO 3 byte QPW
1
Type of drive sequence (Note 1)
4 byte 60VS
2 ABL adjustment table 1 byte 1
3 Type of WB adjustment table
(Note 1)
1 byte 1
4 ABL adjustment value 3 byte 128
5 R-HIGH adjustment value 3 byte 256
6 G-HIGH adjustment value 3 byte 256
7 B-HIGH adjustment value 3 byte 256
15 Center luminance correction 1 byte 0
16 Reserved 1 byte
∗
17 Interlocked with APL 1 byte 0
18
Transition of protective operations
1 byte 0
19
CS
Reserved 2 byte
∗∗
8 R-LOW adjustment value 3 byte 512
9 G-LOW adjustment value 3 byte 512
10 B-LOW adjustment value 3 byte 512
11 R gamma setting 2 byte 31
12 G gamma setting 2 byte 10
13 B gamma setting 2 byte 10
14 Streaking correction 1 byte 1
2 Byte 2 byte 37
15: Center luminance
correction
0 OFF
2 ON (interlocked with APL)
1ON
11, 12, 13: RGB Gamma setting
n 00 to 31
18: Transition of protective
operations
0 Upper limit state for brightness
1 Brightness being reduced
2 Lower limit state for brightness
3
Brightness being increased
17: Interlocked with APL
0 OFF
1ON
2
WB interlocked ON/γ OFF
3
WB interlocked OFF/γ ON
1: Type of Drive
sequence
60VS Video 60 Hz
50VS Video 50 Hz
72VS Video 72 Hz
75V1 Video 75-1 Hz
75V2 Video 75-2 Hz
60PS PC 60 Hz
2: ABL adjustment
table
n n: 1 to 3
3: Type of WB
adjustment table
n n: 1 to 4
Command
Format
Effective Operation
Modes
Function Remarks
[QPW] Every Time
Output of status
Return data: 3 (ECO) + 40 (DATA) + 2 (CS) = 45 Byte
The command QPW is for acquiring the factory-preset data about the video of the panel.
Note 1: The "75 Hz-2" Drive Sequence type signals and WB Adjustment Table 4 are output only
when "75 Hz-2" (VFQS07) is selected for internal signals (mask signals).
When external signals are selected and the Drive Sequence type is 75 Hz, "75 Hz-1" is
output because "75 Hz-1" and "75 Hz-2" are not distinguished for external signals.
