Data Arrangement
Data
Length
Output Example
ECO 3 byte QPM
1 Pulse meter B 1 8 byte 00000000
2 Pulse meter B 2 8 byte 00000000
3 Pulse meter B 3 8 byte 00000000
4 Pulse meter B 4 8 byte 00000000
5
CS
Pulse meter B 5 8 byte 00000000
2 Byte 2 byte E7
Command
Format
Effective Operation
Modes
Function Remarks
[QPM] Every Time
Output of status
Return data: 3 (ECO) + 40 (DATA) + 2 (CS) = 45 Byte
Return data: 3 (ECO) + 69 (DATA) + 2 (CS) = 74 Byte
Note:
The minimum for a returned value of the pulse meter for each
block (B1-B2) is one million.
[8] QPF (FUNCTION OF THE PANEL)
[9] QPM (PULSE METER VALUE)
Data Arrangement
Data
Length
Output Example
ECO 3 byte QPF
1 R-REVISE setting value 1 byte 0
2 G-REVISE setting value 1 byte 0
3 B-REVISE setting value 1 byte 0
4 Reserved 3 byte
∗∗∗
5
ADDRESS L1,L2 setting value
2 byte 01
6
ADDRESS L3,L4 setting value
2 byte 13
7
ADDRESS U1,U2 setting value
2 byte 32
11
Full-screen black display mode
1 byte 1
12 Reserved 4 byte
∗∗∗∗
13 PANEL RX 3 byte 512
8
ADDRESS U3,U4 setting value
2 byte 30
9 Reserved 4 byte
∗∗∗∗
10 Streaking correction 1 byte 1
14 PANEL RY 3 byte 512
15 PANEL GX 3 byte 512
16 PANEL GY 3 byte 512
17 PANEL BX 3 byte 512
18 PANEL BY 3 byte 512
19 Reserved 6 byte
∗∗∗∗∗∗
20 Color sensor R coefficient 3 byte
∗∗∗
21 Color sensor G coefficient 3 byte
∗∗∗
22 Color sensor B coefficient 3 byte
∗∗∗
23 Reserved 12 byte
∗∗ to ∗∗
CS
2 Byte 2 byte 37
Command
Format
Effective Operation
Modes
Function Remarks
[QPF] Every Time
Output of status
The command QPF is for acquiring the characteristic and the function setting value of the panel.
The command QPM is for acquiring the accumulated pulse count.
1: 2: 3: RGB-REVISE setting value
n n: 0 to 7 (Level n)
5 to 8: ADDRESS α, β setting
nm
n: 0 to 9 (Address α setting PHASE n)
m: 0 to 9 (Address β setting PHASE m)
10: Streaking correction
0
n
OFF
n: 1 to 8 (Mode n)
11: Full-screen black display mode
0
1
OFF (In-phase SUS drive prohibition)
MODE1 (In-phase SUS drive permission)
To Next Page
