[6] QAJ (PANEL ADJUSTMENT DATA)
Data Arrangement
Data
Length
Output Example
ECO 3 byte QAJ
1 Vsus adjustment value 3 byte 128
2 Vysnofs adjustment value 3 byte 128
3 Vyprst adjustment value 3 byte 128
4 Vxpofs1 adjustment value 3 byte 128
5 Vxpofs2 adjustment value 3 byte 128
6 Vyknofs1,2 adjustment value 3 byte 128
7 Vyknofs3 adjustment value 3 byte 128
11 R1K adjustment value 3 byte 128
12 R2K adjustment value 3 byte 128
13 Y1K adjustment value 3 byte 128
8 Vyknofs4 adjustment value 3 byte 128
9
Δ Vyknofs1,2/3/4 adjustment value
3 byte 128
10 Reserved 6 byte
∗∗∗∗∗∗
14 Y1Z adjustment value 3 byte 128
15 X1B adjustment value 3 byte 128
16 Y2B adjustment value 3 byte 128
17 X3B adjustment value 3 byte 128
18 YSB adjustment value 3 byte 128
19 XSB adjustment value 3 byte 128
20 YTK adjustment value 3 byte 128
24 YNK adjustment value 3 byte 128
25 SAT adjustment value 3 byte 128
26 Reserved 3 byte
∗∗∗
21 YTZ adjustment value 3 byte 128
22 Y2K adjustment value 3 byte 128
23 Y2Z adjustment value 3 byte 128
27 AM radio countermeasure 1 byte 1
28
CS
Reserved 2 byte
∗∗
2 Byte 2 byte B7
Command
Format
Effective Operation
Modes
Function Remarks
[QAJ] Every Time Output of status Return data: 3 (ECO) + 84 (DATA) + 2 (CS) = 89 Byte
The command QAJ is for acquiring the panel's factory-preset data.
27: AM radio countermeasure
n n: 1 to 8 (SUS frequency n)
