[6] FACTORY HIERARCHICAL TABLE
Large Item
Variable / Adjustment Range Remarks
Middle Item
Small Item
6.2 [1] INFORMATION
[1-1] VERSION (1)
[1-2] VERSION (2)
CLEAR <=> NO <=> YES
CLEAR <=> NO <=> YES
[1-3] MAIN NG
[1-4] TEMPERATURE
[1-5] HOUR METER
[1-6] HDMI SIGNAL INFO 1
[1-8] VDEC SIGNAL INFO 1
[1-7] HDMI SIGNAL INFO 2
[1-9] VDEC SIGNAL INFO 2
6.2 [2] PANEL FACTORY (+)
[2-1] PANEL INFORMATION
[2-2] PANEL WORKS
[2-3] POWER DOWN
[2-4] SHUT DOWN
[2-5] PANEL-1 ADJ (+) VOL SUS <=> 000 to 255
VOL OFFSET <=> 000 to 255
VOL RST P <=> 000 to 255
VOL XPOFS1 <=> 000 to 255
VOL XPOFS2 <=> 000 to 255
VOL YKNOFS1 D <=> 000 to 255
VOL YKNOFS3 D <=> 000 to 255
VOL YKNOFS4 D <=> 000 to 255
VOL YKNOFSA D <=> 000 to 255
RESET1ST_KSB <=> 112 to 144
RESET2ND_KSB <=> 112 to 144
YSTL_1SF_KSB <=> 112 to 144
YSTL_1SF_HZ <=> 112 to 144
XSUS_1ST_B <=> 112 to 144
YSUS_2ND_B <=> 112 to 144
XSUS_3RD_B <=> 112 to 144
YSUS_B <=> 112 to 144
XSUS_B <=> 112 to 144
YSTL_KSB <=> 112 to 144
YSTL_HZ <=> 112 to 144
YSTL_2SF_KSB <=> 112 to 144
YSTL_2SF_HZ <=> 112 to 144
YSTL_FMR_KSB <=> 112 to 144
SCAN ADRS ADJ <=> 112 to 144
SUS FREQ <=> <=> MODE 1 to MODE 8 <=>
[2-6] PANEL-2 ADJ (+) R-HIGH <=> 000 to 999
G-HIGH <=> 000 to 999
B-HIGH <=> 000 to 999
R-LOW <=> 000 to 999
G-LOW <=> 000 to 999
B-LOW <=> 000 to 999
ABL <=> 000 to 255
[2-7] PANEL FUNCTION (+) R-LEVEL <=> <=> LV-0 to LV-7 <=>
G-LEVEL <=> <=> LV-0 to LV-7 <=>
B-LEVEL <=> <=> LV-0 to LV-7 <=>
ADDRESS L1 <=> <=> PH0 to PH9 <=>
ADDRESS L2 <=> <=> PH0 to PH9 <=>
ADDRESS L3 <=> <=> PH0 to PH9<=>
ADDRESS L4 <=> <=> PH0 to PH9 <=>
ADDRESS U1 <=> <=> PH0 to PH9 <=>
ADDRESS U2 <=> <=> PH0 to PH9 <=>
ADDRESS U3 <=> <=> PH0 to PH9 <=>
ADDRESS U4 <=> <=> PH0 to PH9<=>
STK MODE <=> OFF <=> MODE1 to MODE8 <=>
FULL BLACK <=> MODE1 <=> OFF
PANEL RX <=> 000 to 999
PANEL RY <=> 000 to 999
PANEL GX <=> 000 to 999
PANEL GY <=> 000 to 999
PANEL BX <=> 000 to 999
PANEL BY <=> 000 to 999
CLS R <=> 000 to 255
CLS G <=> 000 to 255
CLS B <=> 000 to 255
