Access to SCAN A and B Assys
8
Remov
e the one screw
.
(APZ30P080FTB)
1
Remov
e the two screws
.
(ABZ30P080FTC)
2
Remov
e the two screws
.
(AMZ30P060FTB)
3
Remov
e the F
.
chassis
VL Assy 50.
4
F
.
chassis VL Assy 50
1
2
3
3
2
4
The other screws are random order
.
2
1
Screw tightening or
der
50F Y
DRIVE
Assy
50F SCAN A Assy
50F SCAN B Assy
50F ADDRESS S Assy
50F ADDRESS L Assy
50F ADDRESS S Assy
50F ADDRESS L Assy
