[4] DIGITAL ASSY
Flowchart of Failure Analysis for The DIGITAL Assy
Is an appropriate signal input?
(Check the V frequency with the
QSI command.)
Is the sync signal properly output
from the MAIN Assy?
Disconnect and reconnect the
50P (J212) FFC/40P (J211) FFC.
• If the OSD is not properly displayed although the panel mask is properly displayed,
a failure exists in the path from the output of IC2801 on the MAIN Assy to IC3301 on the DIGITAL Assy.
-> If only the OSD is abnormal, the MAIN Assy is in failure.
• If no vertical sync signal is input to the DIGITAL Assy,
a freeze-frame picture will be displayed.
• It is most likely that the video signal
and sync signal data are abnormal.
No
No
No
NG
Failure in connectors CN3201 or
CN3202 on the DIGITAL Assy.
Failure in ASIC (IC3301) on the
DIGITAL Assy.
Replace the MAIN Assy.
Replace the 50P (J212) FFC/
40P (J211) FFC.
NG
Ye s
OKNG
Replace the DIGITAL Assy.
The on-screen display (OSD) is
not properly indicated.
Failure analysis for the
DIGITAL Assy => DG1
