Pioneer PDP-5020FD User Manual

140
PDP-5020FD
1
2 3 4
A
B
C
D
E
F
1
2 3 4
Operation item
[3-1] CH PRESET <=>
Exclusively used for production line.
[3-2] ANTENNA MODE <=>
Exclusively used for production line.
[3-3] AFT <=>
Exclusively used for production line.
[3-4] SYNC DET (+)
Exclusively used for technical analysis (details omitted).
[3-5] CTI (+)
Exclusively used for technical analysis (details omitted).
[3-6] CC (+)
Exclusively used for technical analysis (details omitted).
No. Function Content RS-232C
[3-1] CH PRESET <=> Set the channel map for production line SCP
[3-2] ANTENNA MODE <=> Switch the CABLE/AIR of the analog tuner INJ
[3-3] AFT <=> Set AFT of the analog broadcasting AFT
[3-4] SYNC DET (+) Set the synchronized signal detection of VDEC
−−−
[3-5] CTI (+) Set the synchronized signal detection of VDEC
−−−
[3-6] CC (+) Set the ClosedCaption signal detection of VDEC
−−−
