[10] QPD (POWER DOWN LOGS)
Data Arrangement
Data
Length
Output Example
ECO 3 byte QPD
1 Latest "1st PD" data 1 byte A
2 Latest "2nd PD" data 1 byte 2
3 Data from the hour meter for the latest PD 8 byte 00010020
4 Second latest "1st PD" data 1 byte E
5 Second latest "2nd PD" data 1 byte 9
6 Data from the hour meter for the second latest PD 8 byte 00008523
7 Third latest "1st PD" data 1 byte 4
8 Third latest "2nd PD" data 1 byte 3
9 Data from the hour meter for the third latest PD 8 byte 00004335
10 Fourth latest "1st PD" data 1 byte 2
11 Fourth latest "2nd PD" data 1 byte 0
12 Data from the hour meter for the fourth latest PD 8 byte 00000945
13 Fifth latest "1st PD" data 1 byte 4
14 Fifth latest "2nd PD" data 1 byte 0
15 Data from the hour meter for the fifth latest PD 8 byte 00000715
16 Sixth latest "1st PD" data 1 byte A
17 Sixth latest "2nd PD" data 1 byte 2
18 Data from the hour meter for the sixth latest PD 8 byte 00000552
19 Seventh latest "1st PD" data 1 byte A
20 Seventh latest "2nd PD" data 1 byte 0
21 Data from the hour meter for the seventh latest PD 8 byte 00000213
22 Eighth latest "1st PD" data 1 byte D
23 Eighth latest "2nd PD" data 1 byte 0
24
CS
Data from the hour meter for the eighth latest PD 8 byte 000001A7
2 Byte 2 byte 27
" PD data
0 No PD
2 P-POWER
3 SCAN
4 SCN-5V
6 Y-DCDC
7 Y-SUS
8 Address
A X-DCDC
B X-SUS
C DIGI-DCDC
F UNKNOWN
Command
Format
Effective Operation
Modes
Function Remarks
[QPD] Every Time Output of status Return data: 3 (ECO) + 80 (DATA) + 2 (CS) = 85 Byte
The command QPD is for acquiring data from the 8 latest power-down (PD) logs.
