7.3
CLUTCHING
SPECIAL CLUTCH TOOLS
CLUTCH TOOLS
All drive clutch maintenance, disassembly and assembly must
be performed only by an authorized Polaris dealer who has
attended current model Dealer Service Seminars, has received
a certificate of completion, and displays the Polaris Servicing
Dealer decal.
Because of the critical nature and precision balance
incorporated into the drive clutch, it is absolutely essential that
no attempt at clutch disassembly and/or repair be made
without factory authorized tools and service procedures. Refer
to the Service Tool Catalog (PN PU03-141) for photos and
descriptions of all tools. A tool catalog update may be
available through the SPX parts department (Phone Number 1-
800-328-6657).
îš‹ = Required Dealer Tool
Table 7-1: Clutch Tools
Offset Alignment Tool PS-46998
îš‹1999 - Current 440, 550 Fuji Engine Drive Clutch Puller 2872084
îš‹1999 - Current 600,700,800 Domestic Engine Clutch Puller 2871855
îš‹1999 - 2001 700,800 XCR Triple Fuji Engine Clutch Puller 2872085
Replacement Handle for ALL Clutch Pullers 5020326
îš‹Drive Clutch Holding Wrench 9314177-A
Strap Wrench PU-45419
Replacement Strap 305085
Drive Clutch Spider Nut Socket 2870338
Drive Clutch Spider Removal and Spider Installation Tool 2870341-A
Pin Centering Tool 2870401
Clutch Pin Installation Tool 2870402
Clutch Pin Punch 2870507
îš‹Tapered Reamer for Drive Clutch Bore 2870576
îš‹Roller Pin Tool 2870910-A
îš‹Drive Clutch Button Removal Tool 2870985
îš‹Clutch Bushing Replacement Tool Kit 2871025
îš‹Primary Clutch Compression Tool 8700220
îš‹Clutch Holding Fixture 2871358
îš‹Clutch Compression Tool 8700220
îš‹Spider Assembly Tool 8700221
îš‹Clutch Compression Tool Extensions for TEAM driven PS-45909
îš‹Clutch Pilot Tool
(used with the 2871358 to compress the clutch) PU-45779
Drive Clutch Compression Tool
(compresses drive clutch whole still on the engine) 2871173
