11.23
REAR SUSPENSION
SPECIAL TOOLS
SHOCK REBUILDING TOOLS
SHOCK MAINTENANCE
SHOCK MAINTENANCE
Changing oil on Shocks is recommended annually and should
be included when performing end of season storage
preparation. This oil change is necessary to avoid any chance
of corrosion which could be caused by moisture
contamination.
When performing maintenance on Shocks, use Gas Shock
Recharging Kit PN 2200421. It consists of the necessary
valves, pressure gauge, and fittings to deflate and pressurize
the shocks. The Body Holder Tool, Internal Floating Piston
(IFP), and Shock Rod Holding Tool are not included in the
Recharging Kit and must be ordered separately. Refer to your
SPX Specialty Tool catalog for part numbers.Videos on shock
Table 11-24: Special Tools
PART NUMBER DESCRIPTION
2200421 Gas Shock Recharging Kit
2201639 Shock Shaft Seal Protector 1/2” Diameter
2201640 Shock Shaft Seal Protector 5/8” Diameter
2870623 Shock Absorber Spring Compression Tool
2870803 Shock Spring Pre-Load Adjustment Too
PS-45259 Gas Fill Tool
9917736 VIDEO-Rebuilding Mono Tube Shocks
9917737 VIDEO-Rebuilding Remote Reservoir Shocks
Table 11-25: Ryde FX Shock Special Tools
PART NUMBER DESCRIPTION
PS-45259 Gas Fill Tool and Gauge (Incl. 5 needles)
PS-45259-1 Gas Fill Needles replacement pack
PS-45259-2 Gas Fill Gauge (replacement)
PS-45260 Lower Retainer Wrench
PS-45261 IFP Positioning / Extraction tool
PS-45262 Cylinder Head Wrench
PS-45263 Wear Band Tool
PS-45629 Arvin Shock Body Holder
PS-45280 Shock Collar Tool
PS-45821 Shock Reservoir Holder
Table 11-26: FOX Shock Special Tools
PART NUMBER DESCRIPTION
2871021 Shock Body Holding Tool
2871352 Shock Rod Holding Tool 1/2" rod
2872429 Shock Rod Holding Tool 5/8" rod
2871232 Fox Shock Spanner
2871351 Fox Shock IFP Depth Tool
PS-44925 Fox Inner Tube Puller PS 2
