SPECIFICATIONS
700 RMK
MODEL NUMBER: S06P(K,L,M)7HS(A,B)
Table 1-277: Engine
Engine type Liberty
Engine displacement 755cc
Bore in/mm 3.05/77.5
Stroke in/mm 3.15/80
Piston to cylinder clearance
in/mm
.0045-.0074/.114-.188
Piston ring end gap .014-.020/.35-.50
Operating RPM ±200 7600
Idle RPM ±200 1600 @ specified TPS setting
Clutch engagement RPM ±200 3700
Exhaust valve spring
Purple
Table 1-278: Fuel Delivery
Type Cleanfire
Throttle body size in/mm 2.0/51
Fuel pressure psi/bar 116/8
Recommended fuel octane
(R+M/2)
91
Table 1-279: Idle TPS voltage setting
Altitude meters/feet Voltage ±.01v
0-1800(0-6000) .93
1800-2700(6000-9000) .95
> 2700 (>9000) .97
Table 1-280: Clutching
ALTITUDE
meters
(feet)
DRIVE CLUTCH (P-85) DRIVEN CLUTCH (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-74
Black/
Green
Red/Black
64/36-25
ER
20:41-76
600-1200
(2000-4000)
10-72
Black/
Green
Red/Black
64/36-25
ER
20:41-76
1200-1800
(4000-6000)
10-70
Black/
Green
Red/Black
64/36-25
ER
20:41-76
1800-2400
(6000-8000)
10-68
Black/
Green
Red/Black
64/36-25
ER
20:41-76
2400-3000
(8000-10000)
10-66
Black/
Green
Red/Black
64/36-25
ER
20:41-76
3000-3600
(10000-12000)
10-64
Black/
Green
Red/Black
64/36-25
ER
20:41-76
Drive clutch bolt torque 96 ft-lbs (130Nm)
Table 1-281: Belt
Belt part number 3211080
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-282: Chaincase
Center distance in/cm 8.373/21.27
Reverse type PERC
Table 1-283: Fluids and capacities
Fuel gal/l 10.8/40.9
Oil qts/l 3/2.8
Coolant qts/l 6.9/6.5
Chaincase oz/ml 11/325.3
Brake fluid type DOT 4
