FRONT SUSPENSION/STEERING
IFS SHOCK PRODUCTION VALVING
The valving charts are listed in compression sections and
rebound sections. A compression stack will be located nearest
the eyelet of the shock rod. A rebound stack will be located
nearest the threaded end of the shock rod.
Table 10-3: IFS 7042258
COMPRESSION
.700x.015
.800x.006
.900x.006
1.000x.006
1.100x.008
1.250x.006
.800x.008
1.100x.006
1.300x.008
Piston orifice .060
REBOUND
1.250x.008
1.100x.008
1.000x.008
.900x.008
.800x.008
.700x.008
Table 10-4: IFS 7043141
COMPRESSION
1.125x.093
.700x.012
.700x.012
.900x.008
1.000x.008
1.100x.008
1.250x.008
.800x.008
1.100x.008
1.300x.006
Piston orifice .078
REBOUND
1.250x.008
.700x.008
1.100x.010
1.000x.010
.900x.012
.800x.012
.700x.012
.620x.093
Table 10-5: IFS 7043095
COMPRESSION
.875x.090
.625x.065
.700x.006
.800x.006
.900x.006
1.000x.006
1.100x.006
.900x.012
1.200x.006
1.000x.012
1.300x.006
Piston orifice .052
REBOUND
1.200x.008
1.100x.008
1.000x.008
.900x.010
.800x.010
.700x.010
.625x.065
ADJUSTER
1.100x.025
1.000x..025
.625x.065
Table 10-6: IFS 7043090
COMPRESSION
.700x.015
.800x.006
.900x.006
1.000x.006
1.100x.008
1.250x.006
.800x.008
1.100x.006
1.300x.008
Piston orifice .081
REBOUND
1.250x.008
1.100x.008
1.000x.008
.900x.008
.800x.008
.700x.008
