12.9
CHASSIS / HOOD
NOSEPAN
REPLACEMENT
IMPORTANT: When installing a replacement
nosepan, the open circles represent rivets installed
from inside the nosepan through the bottom. The
filled in circles represent rivets installed from the
under side of nosepan through to the top.
NOTE: Rivet holes may require drilling into the
bulkhead. When transfer drilling holes do not force
the nosepan into a position which is not uniform to
the other side. Rivet holes across from each other.
DECALS
DECAL REMOVAL
Before you begin, read these instructions and check to be sure
all parts and tools are accounted for.
You will need the following items:
• Squeegee
• Cheese Cloth or a non abrasive cloth
• Paper Shop Towels
• Hair Drier or Heat Gun
• Wallpaper seam roller or similar roller
•3Mt citrus based clear (3Mt PN 62-4615-430-5)
available at most auto parts stores
• Cleaning solution (99% water 1% mild dish washing
detergent)
•ScotchR 233 Performance masking tape
Perform the decal removal procedures carefully! If care is not
taken, the possibility exists that paint could peel from the
hood. Follow each step thoroughly and completely to avoid
hood damage! Polaris is not responsible for any hood or
Cleaning Solution
Cheese cloth
Squeegee
3Mt cleaner
Hair dryer
