7.23
CLUTCHING
POLARIS P-85 HELIX
The helix spring should always be adjusted within its limits before a helix change is performed. The normal rate of change
between helix angle steps is 250 RPM under full throttle. This is approximately the same result as in going from the No. 1 to No.
4 spring position (P-85).
NOTE: Increasing spring tension increases engine RPM. RPM changes may not be evident if other drive or
driven clutch components are substandard.
NOTE: All R-Series, Mod(M), T1, and 40-36 helix ramps are cut 0.060, deeper in the snap ring pocket. These
are made so the driven clutch can open far enough for full shift out with wide 1 7/16, belts.
If these helix ramps are used with narrow belts, 2 (two) additional (for a total of three) .030, /.8 mm washers (PN 7556804) should
be installed under the snap ring to prevent the belt from touching the inner hub at full shift which can cause belt failure. Wide belt
models use only the existing washer under the snap ring.
Table 7-10: Team Driven Ramps for Electric Reverse
PART NUMBER DESCRIPTION PART NUMBER DESCRIPTION
5133687 58/44-46 ER 5134055 54/42-36 ER
5133771 58/42-46 ER 5134095 56/42-36 ER
5133772 62/46-46 ER 5134132 58/42-36 ER
5133773 62/42-46 ER 5134204 64/44-65 ER
5133784 58/40-46 ER 5134226 60/42-75 ER
5133785 62/40-46 ER 5134263 54/38-25 ER
5133786 62/44-46 ER 5134264 64/42-65 ER
5133787 62/48-46 ER 5134721 62/46-36 ER
5133788 66/44-46 ER 5134722 62/42-36 ER
5133789 60/46-46 ER 5134877 64/38-36 ER
5133886 54/42-46 ER 5135057 62/38-36 ER
5133887 S40 ER
5133904 S36 ER
5135256 64/42-36 ER
5135242 64/38-25 ER 5135243 64/36-25 ER
Table 7-11: P-85 Helix
PART NUMBER DESCRIPTION DEGREES
5130896 34 D 34
5130895 36 D 36
5131287 R1 40-32
5131289 R3 45-32
5131290 R4 50-32
5131291 R5 40-34
5131294 R8 50-34
5131295 R9 40-36
5131297 R11 45-36
5131623 R32 50-34
5131298 R12 50-36
5630383 36.5 36.5
5133023 R49 60-23
