1.22
SPECIFICATIONS
700 TOURING
MODEL S06PT7HS
Table 1-129: Engine
Engine type Liberty
Engine displacement 755
Bore in/mm 3.05/77.5
Stroke in/mm 3.15/80
Piston to cylinder clearance in/
mm
.0045-.0074/.114-.188
Piston ring end gap .014-.020/.35-.50
Operating RPM ±200 7600
Idle RPM 1700
Clutch engagement RPM ±200 3700
Exhaust valve spring Purple
Table 1-130: Fuel Delivery
Type Cleanfire
Throttle body size in/mm 2.0/51
Fuel pressure psi/bar 116/8
Recommended fuel octane
(R+M/2)
91
Table 1-131: Idle TPS voltage setting
Altitude meters/feet Voltage ±.01v
0-1800(0-6000) .93
1800-2700(6000-9000) .95
> 2700 (>9000) .97
Table 1-132: Clutching
ALTITUDE
meters
(feet)
DRIVE CLUTCH (P-85) DRIVEN CLUTCH (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-72
Dark Blue /
White
Red/Black
62/42-46
ER
23:39-76
600-1200
(2000-4000)
10-72
Dark Blue /
White
Red/Black
62/42-46
ER
23:39-76
1200-1800
(4000-6000)
10-70
Dark Blue /
White
Red/Black
62/42-46
ER
23:39-76
1800-2400
(6000-8000)
10-68
Black /
Green
Red/Black
62/38-36
ER
22:40-76
2400-3000
(8000-10000)
10-66
Black /
Green
Red/Black
62/38-36
ER
20:41-76
3000-3600
(10000-12000)
10-64
Black /
Green
Red/Black
62/38-36
ER
20:41-76
Drive clutch bolt torque 96 ft-lbs (130Nm)
Table 1-133: Belt
Belt part number 3211080
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-134: Chaincase
Center distance in/cm 8.373/21.27
Reverse type
PERC
Table 1-135: Fluids and capacities
Fuel gal/l 10.8/40.9
Oil qts/l
3/2.8
Coolant qts/l
6.7/6.3
Chaincase oz/ml
11/325.3
Brake fluid type DOT 4
