SPECIFICATIONS
900 SWITCHBACK
MODEL NUMBER: S06PS8DS(A)
Table 1-238: Engine
Engine type Liberty
Engine displacement 866cc
Bore in/mm 3.27/83
Stroke in/mm 3.15/80
Piston to cylinder clearance in/
mm
.0045-.0074/.114-.188
Piston ring end gap .016-.022/.41-.56
Operating RPM ±200 7600
Idle RPM ±200 1700 @ specified TPS setting
Clutch engagement RPM ±200 3700
Exhaust valve spring Purple
Table 1-239: Fuel Delivery
Type Cleanfire Injection
Throttle body size in/mm 2/51
Fuel pressure psi/bar 116/8
Recommended fuel octane
(R+M/2)
91
Table 1-240: Idle TPS voltage setting
Altitude meters/feet Voltage ±.01v
0-1800(0-6000) .93
1800-2700(6000-9000) .95
> 2700 (>9000) .97
Table 1-241: Clutching
ALTITUDE
meters
(feet)
DRIVE CLUTCH (P-85) DRIVEN CLUTCH (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-74
Dark Blue /
White
Red/Black
64/42-46
ER
25:40-78
600-1200
(2000-4000)
10-72
Dark Blue /
White
Red/Black
64/42-46
ER
25:40-78
1200-1800
(4000-6000)
10-72
Dark Blue /
White
Red/Black
64/42-46
ER
25:40-78
1800-2400
(6000-8000)
10-70
Black /
Green
Red/Black
64/38-36
ER
24:41-78
2400-3000
(8000-10000)
10-68
Black /
Green
Red/Black
64/38-36
ER
22:43-78
3000-3600
(10000-12000)
10-66
Black /
Green
Red/Black
64/38-36
ER
22:43-78
Drive clutch bolt torque 96 ft-lbs (130Nm)
Table 1-242: Belt
Belt part number 3211080
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-243: Chaincase
Center distance in/cm 8.373/21.27
Reverse type
PERC
Table 1-244: Fluids and capacities
Fuel gal/l 10.8/40.9
Oil qts/l 3/2.8
Coolant qts/l 6.8/6.4
Chaincase oz/ml 11/325.3
Brake fluid type DOT 4
