SPECIFICATIONS
340 INDY TOURING
MODEL S06NT3AS
Table 1-90: Engine
Engine type Fuji
Engine displacement 339cc
Bore in/mm 2.45/62.3
Stroke in/mm 2.19/55.6
Piston to cylinder clearance in/
mm
.003-.005/.080-.130
Piston ring end gap .008-.014/.20-.350
Operating RPM±200 7000
Idle RPM 1600
Clutch engagement RPM ±200 3700
Table 1-91: Fuel Delivery
Type VM30SS
Main Jet 170
Pilot Jet 35
Jet Needle/Clip position 5DP13/3
Needle Jet O-6(169)
Throttle gap under cutaway
in/mm
.240/6.1
Throttle slide cutaway 2.5AL
Valve seat 1.5 Viton
Starter jet 1.5
Pilot air jet 2.5
Fuel screw setting N/A
Air screw setting 1.5
Recommended fuel octane
(R+M/2)
87 non Oxy/89 Oxy Min
Table 1-92: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -25_F/<-35_C
-30_F to -10_F/-34_C to -23_C
-15_F to +5_F/-26_C to -15_C
0_F to +20_F/-18_C to -7_C
+15_F to +35_F/-9_C to +2_C
+30_F to +50_F/-1_C to +10_C
+45_F to +65_F/+7_C to +18_C
>+60_F/>+16_C
0-600
(0-2000)
185
#4
180
#3
170
#3
170
#3
165
#3
160
#3
155
#3
150
#3
600-1200
(2000-4000)
175
#3
170
#3
160
#3
160
#3
155
#3
150
#3
140
#2
140
#2
1200-1800
(4000-6000)
165
#3
160
#3
155
#3
150
#3
145
#3
140
#2
130
#2
130
#2
1800-2400
(6000-8000)
155
#3
150
#3
140
#3
135
#3
135
#2
130
#2
120
#1
120
#1
2400-3000
(8000-10000)
145
#3
140
#3
130
#2
130
#2
125
#2
120
#1
110
#1
110
#1
3000-3700
(10000-12000)
135
#3
130
#2
120
#2
115
#2
115
#1
110
#1
100
#1
100
#1
Table 1-93: Clutching
Altitude meters
(feet)
Drive Clutch (P-85) Driven Clutch (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-900
(0-3000)
10
Black-
2287
Blue/
Black
54/38-
25ER
17:41-72
900-1800
(3000-6000)
10-M
Blue
Black-
2287
Blue/
Black
54/38-
25ER
17:41-72
1800-2700
(6000-9000)
10 MW
Black-
2287
Blue/
Black
54/38-
25ER
17:41-72
2700-3700
(9000-12000)
10 MR
Black-
2287
Blue/
Black
54/38-
25ER
17:41-72
Drive clutch bolt torque 50 ft-lbs(69Nm)
Table 1-94: Belt
Belt part number 3211078
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-95: Chaincase
Center distance in/cm 7.92/20.1
Reverse type PERC
