Polaris 340 CLASSIC 2006 User Manual

1.15
SPECIFICATIONS
Table 1-82: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l N/A
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-83: IQ Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm .82/2.1
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
.375-.5/1-1.3
Table 1-84: M-10 Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm 1/2.5
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
.875-1.13/2.2-2.9
Table 1-85: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041932
IFS spring rate lbs-in/kg-mm 100/1.79
Spring installed length in/cm 9.81/24.9
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-86: Edge Rear Suspension
Front track shock (FTS) Arvin/7041939*
FTS spring rate
lbs-in/kg-mm
200 Var/ 3.6Var
FTS spring installed length
in/cm
7.5/19.1
Rear track shock Fox/7042129*
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-87: M-10 Rear Suspension
Front track shock Fox/7042224*
Front track shock spring rate
lbs-in/kg-mm
160/2.9
Spring installed length in/cm 8.375/21.3
Rear track shock Fox/7042216*
Rear track shock spring
(RTS) part number
7041935-7041936
RTS spring rate
lbs-in/kg-mm
185 Var-1000/3.3-17.9
RTS Installed length 10.5/26.7
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-88: Dimensions
Width in/cm 47.25/120
Length in/cm 113/287
Height in/cm 46/117
Est dry weight lb/kg
EDGE 477/216.4
M-10 470/213.2
Table 1-89: Electrical
Ignition timing 27_@3000
Spark plug gap in/mm .028/.70
Spark plug NGK BR9ES
Voltage regulator/output 240watt
Magneto pulse 6
CDI marking CU7242
