1.30
SPECIFICATIONS
600 HO DRAGON FUSION
MODEL S06MC6FS
Table 1-182: Engine
Engine type 600 Liberty
Engine displacement 599cc
Bore in/mm 3.04/77.25
Stroke in/mm 2.52/64
Piston to cylinder clearance
in/mm
.0045-.0059/.114-.150
Piston ring end gap .014-.020/.36-.51
Operating RPM 8100
Idle RPM 1500
Clutch engagement RPM +/-
200
3800
Exhaust valve spring Pink
Table 1-183: Fuel Delivery
Type TM38
Main Jet 420
Pilot Jet 50
Jet Needle/Clip position 9DGN6-57/2
Needle Jet P-8
Throttle gap under cutaway
in/mm
.083/2.1
Throttle slide cutaway 1.5 Notch
Valve seat 1.5
Starter jet 145
Pilot air jet .6
Fuel screw setting 1.25
Air screw setting N/A
Recommended fuel octane
(R+M/2)
91
Table 1-184: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -25_F/<-35_C
-30_F to -10_F/-34_C to -23_C
-15_F to +5_F/-26_C to -15_C
0_F to +20_F/-18_C to -7_C
+15_F to +35_F/-9_C to +2_C
+30_F to +50_F/-1_C to +10_C
+45_F to +65_F/+7_C to +18_C
>+60_F/>+16_C
0-600
(0-2000)
440
#3
430
#3
420
#2
400
#2
390
#2
380
#2
370
#2
360
#1
600-1200 (2000-
4000)
410
#3
400
#3
390
#2
370
#2
360
#2
350
#2
340
#1
330
#1
1200-1800
(4000-6000)
370
#3
360
#2
350
#2
340
#2
330
#2
320
#1
310
#1
300
#1
1800-2400
(6000-8000)
340
#3
320
#2
310
#2
300
#2
280
#2
280
#1
270
#1
260
#1
2400-3000
(8000-10000)
310
#2
300
#2
290
#2
280
#1
270
#1
260
#1
250
#1
240
#1
3000-3700
(10000-12000)
290
#2
280
#2
270
#1
250
#1
240
#1
230
#1
220
#1
210
#1
When using non oxygenated fuel with an octane number
greater than 93, decrease the main jet number in the above
chart by 10 and insert the E-clip one position. If already in
position #1 install washer on top when using the above
fuel.
Table 1-185: Clutching
Altitude meters
(feet)
Drive Clutch (P-85) Driven Clutch (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-62
Black/
Green
Red/
Black
56/42-36 20:41-76
600-1200
(2000-4000)
10-60
Black/
Green
Red/
Black
56/42-36 20:41-76
1200-1800
(4000-6000)
10-58
Black/
Green
Red/
Black
56/42-36 20:41-76
1800-2400
(6000-8000)
10-56
Black/
Green
Red/
Black
56/42-36 20:41-76
2400-3000
(8000-10000)
10-54
Black/
Green
Red/
Black
56/42-36 20:41-76
3000-3700
(10000-12000)
10AL
Black/
Green
Red/
Black
56/42-36 20:41-76
Drive clutch bolt torque 50 ft-lbs
Table 1-186: Belt
Belt part number 3211080
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
