11.20
REAR SUSPENSION
SHOCK VALVE PART NUMBERS
Shock valves are used in a stack on the top and on the bottom
of the shock piston. These stacks can be adjusted so that it can
control the amount of fluid that is forced by as the piston
travels through its motion. Below is a chart that has the part
numbers of these valves, proceeding the part number is the
size of the washer (out side diameter x thickness). A thick
washer (.700 x .010) will try to keep the fluid from passing
through the piston as it travels.
Refer to the appropriate parts manual for a complete listing of
shock parts.
