QSC touchmix-30 pro User Manual

126
1001108-01-F
TouchMix Block Diagram
Mic/Line Input Channels
Mic/Line Input Channels
Main Outputs
L R
Cue
L R
Aux (Odd)
To Multi-Track
FX Sub-Groups (odd) *
Sub-Groups (even) *
Aux (Even)
Meter
1 per Mixer
Assignable
Pitch
Corrector
Ch Fader
Pre
Post
Digital
Gain
Trim
From DCA
Masters
Digital
Gain
Pre
Post
Detector In
Post Fdr
Pre Fdr
Pre Dyn
Pre all
RTA
Side
Chain
Pre
Post
Input
Digital
Patch Matrix*
Mute
Logic
A/D
Mic
Pre
Over
Side Chain
Matrix
TouchMix-30: Ch 1 - 20
TouchMix-16: Ch 1 - 12
TouchMix-8: Ch 5 - 8
FX Send
Pre
Post
Record Pick-Off
(Global)
TouchMix-30: Ch 21 - 24
TouchMix-16: Ch 13 - 16
TouchMix-8: Ch 2 & 3
TouchMix-8: Ch 1 & 2
* TouchMix-30 only
Aux Send
(to stereo)
Aux Send
(to mono)
Post Fdr
Pre Fdr
Pre Dyn
Pre all
Assign
DAW*
USB Drive
Recording Mode*
USB Drive
DAW*
TouchMix-16: In 16
TouchMix-8: In 8
To Room Tuning Wizard
Pan
Polarity
Φ
Delay Low Cut High Cut PEQ Comp
Gain
Gain
Gate
Mute
Pan
Mute
Mute
+48 V
Trim
Mic
Pre
+48 V
Pad
Trim
Mic
Pre
+48 V
Pad
Hi-Z
Pad
Hi-Z
Cue
Mute
To DAW*

QSC touchmix-30 pro Specifications

General

Type	Digital Mixer
Channels	32
USB Interface	Yes
Effects Processors	4
Wireless Control	Yes
Phantom Power	Yes
Outputs - Aux	6
EQ Bands	4-band parametric
Computer Connectivity	USB
A/D Resolution	24-bit
Sampling Rate	48kHz
Bit Depth	24-bit
Wireless Control Platforms	iOS, Android
Aux Outputs	6
Main Outputs	2
Touchscreen	Yes
Headphones	1
Effects	Reverb, Delay, Chorus
USB	2.0
Power Source	AC
Display	10-inch Touchscreen
Stereo Line Inputs	2 stereo pairs
Inputs - Line	2 stereo pairs
